PRODUCTION EQUIPMENTS

All the department managers are senior staffs who would guarantee the production efficiency and quality control
with their more than 10-year’s working experience and stability.

KODAK CTP

Introduction to the functional superiorities of Kodak 1600CTP plate maker

  1. Full-open type of plate maker with the largest plate size of 1620*1240;
  2. The advantages of “square light spot”: extremely fast ink-water balance, making high-quality products at low cost, saving time for changing version, allow for printing FM screening on a large scale;
  3. Temperature compensation patent: ensure precise alignment under large temperature difference;
  4. Fast and dynamic automatic focusing: prevent thermal point defects or image defects due to small dust particles;
  5. Geometric correction: rectify tiny geometric wraps of plates, so that any two equipments can be a printing plate for imaging together.



GEMAN ROLAND 5C OFFSET PRINTER

German Manroland printing press

German Manroland printing press is one of the first-class brands of offset lithography equipments. It has highly precise overprinting device, quick switching and polishing device, inking unit with double ink flow, automatic rubber cloth cleaning device, automatic impression cylinder washers, and substrate materials of good universality, etc.

GERMAN ROLAND PRINTER

Max Size :1420*1020mm
Min Size :600*850mm
Speed :15200 /H
Error Value :0.2mm

UV/PP COATING

UV full automatic glazing machine
maximum width :1450 mm

Max Wide :1100MM
Max Size :4000 H
Error Value : ±1MM

Fully automatic film covering machine
maximum width :1450 mm

Max Wide :1100MM
Max Size :4200 /H
Error Value : ±1MM

MOUNTED PAPER MACHINE

Fully automatic Laminating Machinemaximum width :1450 mm

MAX SIZE : 1450*1450MM
MINIMUM PRODUCTION SPECIFICATION/MIN SIZE : 400*400MM
MAXIMUM PRODUCTION RATE/SPEED : 6000 SHEETS/H
EQUIPMENT ACCURACY/ERROR VALUE : +1.5MM

MAX SIZE : 1450*1450MM
MINIMUM PRODUCTION SPECIFICATION/MIN SIZE : 400*400MM
MAXIMUM PRODUCTION RATE/SPEED : 4000 SHEETS/H
EQUIPMENT ACCURACY/ERROR VALUE : +1MM

DIE-CUT MACHINE

Fully automatic film cutting machine,maximum width :1450 mm,1500mm,1620mm, Applicable to all kinds of corrugated color boxes and card boxes.

MAX SIZE: 1450*1020MM
MINIMUM PRODUCTION SPECIFICATION/MAX SIZE:600*400MM
MAXIMUM PRODUCTION RATE/SPEED:4500 RPM/H
EQUIPMENT ACCURACY/ERROR VALUE: +0.5MM

MAX SIZE: 1620*1200MM
MINIMUM PRODUCTION SPECIFICATION/MAX SIZE:650*450MM
MAXIMUM PRODUCTION RATE/SPEED:6000 RPM/H
EQUIPMENT ACCURACY/ERROR VALUE: +0.5MM

GLUING MACHINE

ORIGIN: SEMI, ZHEJIANG, CHINA
MAX SIZE: 1400*1200MM
MAXIMUM PRODUCTION RATE/SPEED: 1500 SHEETS/H
EQUIPMENT ACCURACY/ERROR VALUE: +1MM

MAX SIZE: 2000*1000MM
MAXIMUM PRODUCTION RATE/SPEED: 3000 SHEETS/H
EQUIPMENT ACCURACY/ERROR VALUE: +1MM

FT-S610 Angle Board Machine

(V Profile + notching)
